COMMON USE TYPE 2-WAY SOLENOID VALVES
1. Small Size, high flow, little electric power required.
2. Product part can change.
3. Coil can arbitrarily revolve.
4. Water proof coil available when required.
Normally closed solenoid valve, connection size : 3/8"~2" Pipe. For Fluid : Water, Air, Gas, Oil, Vacuum.
1. 2-way normally closed solenoid valve.
2. Forged brass body .
3. Mountable in any position without
affecting operation. Level pipes
installed, that is best for long life.
4. Standard voltage: AC 110V / 220V
(50 / 60Hz)
5. Other voltage of AC/DC available when
6. Voltage is white ±10％ differential.
7. Normally open solenoid valve available
Items of Attention
1. Not for fluid of viscosity over 50 cst.
2. Not for liquids that solidify when cool.
3. Not for Corrosive fluid.
4. Pipes must be washed neat and clean
5.. A Y-STRAINER has to be installed in
the front of solenoid valve, that is best
for long life.
6. Use in Gas and Oil can use G type
